19"-Swing frame 0361

0361-7009-60-07

19"-Swing frame 0361

  • For accommodating 19“-components
  • Can be pivoted from 0-90°

Product description

No cross bar required, as pivot point and lock are on the same side.

Connection of protective earth conductor according to DIN EN 61439-1, connection on frame.

To house slide-in modules, sub-racks etc.

Can be mounted in häwa free-standing and modular cabinets and in wall-mount enclosures Serie 3331.

Left-hand or right-hand hinging.

Lock: casement fastener with 3 mm dual-bit lock.

Load capacity: max. 40 kg.

Technical Data

  • Order No.: 0361-7009-60-07
  • Dimension: Suitabel for width : 600 mm
  • Surface: Powder coating RAL 7035, texture finish
  • Construction height: HE/U9
  • Material: Sheet steel
  • Weight: 3 kg
  • Sheet thickness: 1,5 mm
  • Dimension H: 544.5 mm
  • Dimension height H: 441.5 mm

Notice

  • See accessories for mounting hardware for the installation in cabinets or wall-mount enclosures.
  • Please observe the mounting instructions in the download!
  • 1 complete swing frame
