3128-1500-22-37
Roof-Mounted Air Conditioner with Filter and Compact Controller
- Compact design
- High cooling capacity
- Protection class: IP54
- Resistant
- Approval: CE
Product description
häwa air conditioners can be us as independent devices up to an ambient temperature of max. 50/55 °C. They have two separate IP54-sealed air circuits, equipped with 1 fan each.
Heat transfer from the inside of the cabinet to the outside takes place through active cooling (refrigerating unit).
This allows to cool down the temperature in the cabinet below the ambient temperature. häwa air conditioners operate with the CFC-free, ozone-friendly refrigerant R134a.
Roof-mounted
External fan operates only when cooling, which avoids unnecessary noise and pollution.
The temperature is set at the factory to +35 °C. It can be field-adjusted from the outside at the controller display.
A control line for the door switch, separately connected for units with a cooling capacity of 800 W or more, permits remote ON/OFF switching of the unit without power disconnect. General fault signal as potential-free changeover contact fed out in the control line.
Free from silicone compounds, PCB, PCT, formaldehyde and cadmium.
Standard controller KR-HS: Circuit board with one temperature gauge integrated in the device.
Display controller KR-HD: Circuit board with 4 temperature gauges integrated in the device and control unit KR-B built into the front panel of the device. The internal fan is controlled via the door switch.
The condensation is drained off directly via a discharge nozzle in the rear panel of the device.
Power connection via a power cord fed through the air inlet.
Technical data
-
Article number: 3128-1500-22-37
-
Frequency: 50 Hz/60 Hz
-
Protection class: IP54, external fan IP44
-
UMGEBUNGSTEMPERATUR_DICT: from: +20 °C/+68 °F to: +55 °C/+131 °F
-
Refrigerant: R134a
-
KUEHLLEISTUNG: 1440 W
-
Nominal voltage: 230 V AC
-
LUFTLEISTUNG: Cold/warm side: 575/860 m³/h
-
Material: Sheet steel
-
Regulation: Compact Controller
-
Factory setting: +35 °C/+95 °F
-
Mounting type: roof-mounted
-
Electrical connection: power cord
-
LEISTUNGSAUFNAHME: at 50 Hz: 800 W
-
NENNSTROM: at 50 Hz: 4,5 A
-
Starting current: 22 A
-
Authorization: CE
-
Weight: 51 kg
-
Dimensions: Width : 600 mm Height : 420 mm Depth : 375 mm
-
Surface: Powder coating RAL 7035, texture finish
-
SICHERUNG: 10 AT
-
type: KA1500F-RD
Notice
- Power consumption and useful cooling capacity specifications relate to L35-L35 according to DIN 3168 and DIN EN 14511. Three-phase devices can also be operated with 460V/60Hz.
- Air conditioner
- Power cord
- Rubber seals
- Mounting hardware
